GM Truck (CUCV) - Winch Mount v2

Lead Times:  3-4 weeks.

Description:

The CUCV is based on a 1984 Chevy K30 and was produced by GM for the military from 1984-1987.  This winch mount is designed to work with the CUCV with minor alterations to the truck.  It is mounted using the 6x bolt locations on the bumper.  There are 2 additional holes that will need to be drilled in the brush guard for the vertical mounts.

It is 1/4" HRPO A36 steel with the exception of the 2x wings, which are 11 gauge (1/8").  The winch bolt pattern is 10" x 4.5" and the fairlead bolt pattern is 10".  Max dimensions are 23.75" L x 9" D. Hardware is included.  Winch, fairlead, shackles, and lights are not included.  Ships bare metal ready for paint or powder coat.  Tested for use up to a 12,000 lbs winch.

The DIY version has tab and slot to aid in welding.

Instructions

Designed and Manufactured in the USA

Hardware info: All Grade 8.  USA made is prioritized, however may be globally sourced if needed due to lead times.

1/2"-13 hex bolt, 2" x8

1/2"-13 hex bolt, 1.5" x6

1/2"-13 hex nut x14

1/2" washer x20

1/2" lock washer x14

Shipping info:

Weight: 55 lbs

Box:  36" x 12" x 12"
